Bitumen Tanker
Hot bitumen and asphalt binder
A specialized tanker for road construction and asphalt production, featuring three-layer insulated body that maintains bitumen temperature at 150–200°C for hours during transport.
.jpg&w=3840&q=75)
Designed for Hot Bitumen Transportation.
The Bitumen Tanker is engineered to transport hot bitumen used in road construction and asphalt production without heat loss. Its three-layer insulated body preserves bitumen temperature at 150–200°C for extended periods.
Inner body made of heat-resistant steel, outer layer stainless/galvanized, with high-density mineral wool insulation between layers. Optional reheating via burner or hot oil circulation, BPW/SAF axles, WABCO EBS, air suspension.
Capacity, insulation thickness, heating system, discharge pump, and filling configuration are customized according to customer requirements.
Specifications
98/91 EEC standards; made of two welded longitudinal I-beams with cross beams at needed distances (Optional special Strenx® 700MC steel for lightweight design)
Body is made of ST-52 (S355JR) for maximum abrasiveness and impact resistance (Optional special Hardox® 450 and Hardox® 500 Tuf steel for lightweight design)
4 mm side, front and back walls, 5 mm floor thickness (Optional: desired thickness)
Mechanical open, lengthwise, top-hinged (Optional hydraulic)
Movable rear bumper compliant with 70/221/EEC standards and tested (Optional: dipped galvanized abrasion- and corrosion-resistant rear bumper)
Optional: manual sliding tarpaulin with continuous rail, electrical sliding and protective tarpaulin
Every detail, deliberate.
EU type approval
98/91 EEC homologation and full compliance with road regulations across the EU, GCC, and CIS.
Premium running gear
BPW or SAF axles with air suspension, EBS brakes, and optional lift axle for payload efficiency.
High-tensile steel chassis
S700 MC–S960 MC steel reduces tare weight without compromising structural integrity.
Built-in corrosion protection
Grit-blasted, epoxy primed, 2K polyurethane top-coat — engineered for a 15-year service life.
Global after-sales
24/7 technical support, spare-parts network across 40+ countries, on-site commissioning.
Tailored to your operation
Customizable dimensions, paint, axle layout, and accessories to match your fleet standards.
